Celestial Star QAL: Join Wedges and Finish Block

Celestial Star QAL: Join Wedges and Finish Block

This Quilt Along originally appeared on my blog in 2014.
All of the posts for the QAL can be found HERE.
For my quilt the fabrics I'm using are Anna Maria Horner and Kona Cotton white.
You can purchase the Celestial Star pattern HERE.

Today's Topic: Join wedges and finish block

Assignment: Join all 12 wedges and complete your block.

After piecing all your segments, and trimming and joining them to create 12 wedges, we will now join those wedges to create a complete quilt block. I have gotten the best results using the following methods and I'm excited to share these methods with you now.

JOIN WEDGES

To keep everything in the correct order, lay out your wedges in the desired order. We will first create 2 halves with 6 wedges each.

Here are my 12 wedges in the order they will go.

1. Take two sections.

2. Draw a line of glue along the edge of one pattern (1st pattern), on the side that will be sewn. Keep the glue close to the edge, within the seam allowance. You don't want to sew on the glue line, but if you do, it won't harm or gunk up your machine.



3. Flip the second pattern over so right sides are facing, and align it on top of the first pattern. Make sure the edges are flush so your seam allowance will be the same on each pattern. Also pay attention that the seam lines that meet up on each pattern are aligned. Here are some simple pictures of how I do this as I lay the second pattern on top of the first. I also made a quick video of this.



First I match the center seam (where the two segments in a wedge join).



Then I match the next seams on the inner pattern.

Then carefully align the points of that last seam. See in the photo above how the line between the white fabric and the orange feather continues straight across to the first pattern?! That is a good sign that I am right on track for a perfect alignment.

Repeat this same process going out from the center to the outside.



You can double check your seam alignment from the side

Here is a super quick video of this process.



4. Do a quick press with the iron to set the glue.



5. Here is what it should look like



6. Now we will sew the two wedges together. Start from the center and align your needle with the point of the pattern, inside the seam allowance.



7. Sew a few stitches and backstitch, securing the stitches as we will not be sewing over these seams later.



Here is the tip of my pattern after sewing. Don't sew past the point of the pattern!

8. Sew along the rest of the edge, keeping an even 1/4" seam allowance. Sew all the way off the edge of the fabric.



Here are my wedges sewn together.

It can be hard to get a perfectly straight line. Don't be discouraged by imperfection.* BUT the most important places to get that perfect seam allowance** is where seams meet. Where the sew lines meet the edge of the paper on the pattern, are where you need to have that "perfect" seam allowance. This will really help you to get results you will be happy with.

*That being said, still get as close to perfect as you can. Just don't feel bad if it's not. ;)

**Glue basting does wonders in this department. In my experience, when I haven't glue basted, though I might sew perfectly straight on the lines, one layer might shift in or out; which means that it didn't have a 1/4" seam allowance; which means that my points don't match up. Glue basting has brought me so much happiness and celebration to my quilting in terms of my end results!! :D If you want to learn more about glue basting, go read Cristy's blo, Sew Much Like Mom. She has taught me everything I know, in the glue department anyway.

9. Remove the paper from the seam allowance ONLY. I leave the paper on the very point, to help me with aligning the tip of my next pattern piece. It helps keep the paper from shifting once it's no longer sewn in.



10. Press your seams away from the side that you are going to add your next wedge to. (See step 16 for details).



11. Now repeat the steps, adding the next (3rd) wedge:

12. Draw a line of glue along the edge of the pattern.



Also notice how the shape of the tip of the pattern (with the white center point) continues on like it hasn't been sewn to? It is the same shape pre-joining. (Not sure how to explain that with words.) This really helps with aligning your pattern, and just works really well!! This is how you know that you've pressed your seam the right direction. (See step 16 for visual comparisons).

13. Align the pattern pieces, being careful to match the seams. Press with a hot iron.



14. Sew along the edge with a 1/4" seam allowance. Remember to start on the point of the pattern, backstitch, and sew toward the outside of the pattern.



15. Remove the paper from the seam allowance only, leaving the paper at the tip.

16. Press seams to the same side as before.



Here is an example of what it looks like when pressed in the wrong direction (I will be adding my next section to the pink side). Notice how it distorts the shape of the pattern?
and here it is pressed in the correct direction. The pattern retains its shape.
17. Repeat again with the next (4th) wedge.
18. Draw a line of glue along the edge.
Here's a close up of my glue line
19. Flip the 4th wedge over and align the seams and edges. Press with a hot iron.
20. Sew along the edge, starting at the center point, backstitch, and sew outward.
Here is the other side. Notice how my seams are all pressed in the same direction, away from the wedge most recently joined. Also notice how the center seams of my wedges are alternating.
21. Remove the paper from the seam allowance ONLY. Leave the paper at the tip.
Here is an example of some paper that I left at the tip, which after both sides of the pattern piece are joined, can then be removed.
Here is where my block is at right now.
22. Repeat these steps with the next (5th) wedge. (In error for my tutorial I pieced the 5th and 6th wedges first. Because I've already piece the other half of my block, this meant that my seams where going the wrong direction to teach you the correct way to do it, so here are my images for joining these last two blocks. I recommend however, to join them all individually, rather than in pairs. Hopefully this doesn't confuse anyone.)
23-24. Draw a line of glue along the edge of the growing block. Align seams and edges of wedges. Press with a hot iron to set the glue.
25. Start at the center point, being careful not to sew through any layers except of the two wedges you are currently joining. If you have been constant at starting at the point, you shouldn't have any problem accomplishing this. Backstitch and sew outwards.
26. Remove paper from the seam allowance ONLY. Leaving paper at the tip. Press your seams to the side.
27. Here is where you would then repeat these steps one more time to join the 6th wedge.
You will now have half of a block, with 6 wedges. With all of your seams pressed in the same direction, they should perfectly align with this center edge of your pattern.



I made the mistake of trimming some of my center points. It's tempting. DON'T DO IT! Leave them there, even though you may think it will be helpful, it's not. Put the scissors down. ;)

28. Repeat ALL these steps to create the other half of your block. Continuing in the order that you were going with the first half. So the first wedge I would join for the other half would be the blue center wedge piece. Continuing in the same order will ensure that the seams are pressed in the correct direction on both halves of your block.

JOIN HALVES

Now you should have two halves of your block. Here are mine.

Here they are on my ironing board ready to join. :)

1. Take one half of your block, and draw a thin line of glue along the entire center edge. (Sorry, I forgot to take a picture of it with glue.)

2. Flip the other half of the block over so right sides are facing, and generally align the two block halves.



3. Now carefully, just as with joining individual wedges, you are going to start from the center, and align the seams and edges going outward. First align the center points, making sure the center diamonds on the edge of each half are perfectly overlapping. Then match each seam going out. As you align each portion, press down firmly, to secure placement with the glue. (refer to the video on the first section of this tutorial, step 3, if you need more visual instruction. This is rather difficult to photograph.)

4. Press with a hot iron after it is all aligned, setting the glue (which gives it a more secure hold).



5. Repeat in exactly the same manner on the other side, starting in the center working out.

6. Press this side with a hot iron, setting the glue.



7. Now we will sew the two halves together. We will do this in the same manner as we joined all the wedges. We will start at the same center point, backstitch, and sew out. Sewing one side, and then repeating with the other.

Because the seams are pressed toward the seam that you want to sew, you will need to lift those center points out of the way so you can get to the center point on the pattern. (PLEASE IGNORE: that I already sewed the seam in these pictures. I wanted to make sure this would work before I shared it with you. Ignore that I tore out the paper from the center point already. Ignore that I trimmed my center points, they should be long, pointy, and in the way.) ;)



Put your needle down at the center point, sew forward and backstitch. You never want to go into the seam allowance from the center point when doing this section. (My sewing foot is up to give you better visual of where my needle is.)



8. Once you have sewn both sides of the center seam. Press the seams to set the stitches.



9. Remove the paper from the seam allowances, including the center points. Press your seams to the sides, in the same direction as the rest of your seams.



10. Pressing all the seams in the same direction creates a spinning seam, and you can then press your center points out into a nice spinning center. I trimmed my points, so it doesn't look the same, but if you keep your points, as you should, you can spin them and press them nice and flat. It really reduces the bulk in the center of your block, which makes it much nicer for quilting!!



11. Press your block on the front and you have a beautiful Celestial Star Quilt Block!!!



12. If you are finished with your quilt block, you may remove all the paper from the back. If you will be adding sashing, a border, or sewing it to more quilt blocks, I recommend leaving the paper on until the you are completely sewing any and all edges of your block. Because your fabric is most likely cut on the bias, or has bias edges, they are more likely to stretch and cause distortion. Leaving the paper on adds stability and will help keep it from stretching or shifting when joining with other fabric.

And that's it!!

Drop in on Friday for Courtney's fabulous guest post, to see her tips and learn how she joins her wedges and halves to create an amazing Celestial Steal Block using beautiful Cotton + Steel fabrics!!! You don't want to miss it. ;)

Any questions?? Otherwise I'm planning on taking somewhat of a break from blogging next week so I can actually finish up all my blocks! ;) But if you do have questions, please ask!! I want the entire process to be as clear as mud. ;) haha.

Otherwise, start sewing and share your finished block(s)  and share your progress of course! I am definitely enjoying seeing everyone's beautiful blocks come together! Great job y'all!! :)
